Adaptor USB

6W Adaptor USB | Made in China

Safety: UL,FCC
EMC Requirement: FCC part 15
Meet environmental standards: RoHS, Reach
符合能效: NRCAN, ENERGY STAR®,CEC,ERP LEVEL V
Operation Temperature: 0~40°C
Relative Humidity: 10%~90%
Storage Temperature: -30~70°C
Hi-Port: 3000VAC 1min
Protection Requirement: Short Circuit、Over current、Over Voltage
Fully sealed, small size and light weight
Input
Input Voltage: 100~240VAC
Frequency: 47~50/60~63Hz
Input Current: 0.3A(Max)
Inrush Current: 240VAC,1.2A (Max)
Leakage Current: 0.25mA(Max)
Output
Power Output: 6W
Line Regulation: < 2.0%
Load Regulation: < 5.0%
Turn On Delay Time: < 5S @ 100VAC
Hold Up Time: 5ms@100VAC
Ripple and Noise: 1% (Max)

Output Voltage Current Output power
5.0-9VDC 1.2A MAX 6W
